atmega128 - LED 순서 제어 #3





[이진법 코드]



#include <avr/io.h>

void delay_sec(int sec)
{
	volatile int i, j, k;
	for (k=0; k<sec;k++) {
		for (i=0; i<1000;i++) {
			for (j=0; j<900; j++) {

			}
		}
	}



}

int main(void)
{
	DDRA = 0x01;
	while(1)
	{
		PORTA = 0b00000001;
		delay_sec(1);
		PORTA = 0b00000010;
		delay_sec(1);
		PORTA = 0b00000100;
		delay_sec(1);
	}
}







[16진법 코드]

#include <avr/io.h>

void delay_sec(int sec)
{
	volatile int i, j, k;
	for (k=0; k<sec;k++) {
		for (i=0; i<1000;i++) {
			for (j=0; j<900; j++) {

			}
		}
	}



}

int main(void)
{
	DDRA = 0x01;
	while(1)
	{
		PORTA = 0x01;
		delay_sec(1);
		PORTA = 0x02;
		delay_sec(1);
		PORTA = 0x04;
		delay_sec(1);
	}
}
